15 - Guide rail
❑ For mounting window channel.
❑ Removing and installing ⇒ page 374
16 - Bracket
❑ For mounting guide rail.
17 - Bolt
❑ For door lock
❑ Qty. 2
❑ Specified torque: 20 Nm
18 - Clamping bracket
19 - Spreader pin
❑ For securing door window
20 - Spreader plug
❑ For securing door window
21 - Cover
22 - Loudspeakers
❑ Attached with 3 rivets.
23 - Rivet
❑ Qty. 3
24 - Bolt
❑ Qty. 10
❑ Specified torque: 8 Nm
25 - Connector
4.3 Removing and installing door window
Note
Removal and installation are described only for the right rear door
window. The removal and installation of the left rear door window
is similar.
4.3.1 Removing window slot seal
Note
Window slot seal should not be bent when removing.
Passat 2011 ➤ , Passat Variant 2011 ➤
General body repairs, exterior - Edition 06.2019
4. Rear door window (estate) 367
