3.4 Removing and installing window regula‐
tor motor
Note
The removal and installation sequence is for the right window
regulator motor only. The removal and installation of the left win‐
dow regulator motor is similar.
3.4.1 Removing
– Remove door trim ⇒ General body repairs, interior; Rep. gr.
70 ; Door trims, saloon and estate .
– Secure door window against sliding down with adhesive tape.
– Unscrew the three bolts -3-.
– Separate electrical connector -2-.
– Remove window regulator motor with control unit -1- from as‐
sembly carrier.
3.4.2 Installing
WARNING
If a new window regulator motor is installed (door control unit),
the additional functions and the excess force limitation feature
have to be coded!
– Position window regulator motor and gently pull door window
up and down to facilitate motor and cable drum toothing inter‐
mesh.
– Specified torque of window regulator motor bolts: 3.5 Nm
– A new window regulator motor is coded using vehicle diagno‐
sis, testing and information system - VAS 5051 A- .
– After coding, allow the window regulator to run upwards once
onto stop in automatic mode and pull switch again for 2 sec‐
onds. This programs the upper stop for the window regulator
motor.
– Then perform remaining installation in reverse order of remov‐
al.
Passat 2011 ➤ , Passat Variant 2011 ➤
General body repairs, exterior - Edition 06.2019
360 Rep. gr.64 - Glazing
