3.5 Removing and installing lock cylinder
housing cover cap
3.5.1 Removing
Note
When removing lock cylinder housing cap, the emergency key
should not be turned and the emergency key should not be used
as a lever.
– Remove emergency key from remote control key.
– Push emergency key -3- lightly -arrow a- in opening on un‐
derside of lock cylinder housing cap.
– Pull lock cylinder housing cap -1-, together with emergency
key, off door lightly from underside -arrow b-.
– Slide off cap upwards -arrow c- from lock cylinder housing.
3.5.2 Installing
– Place lock cylinder housing cover cap -2- from above
-arrow a- on lock cylinder housing at a slight angle.
– Push lock cylinder housing cover cap -2- on door -arrow b-
until cover cap engages in lock cylinder housing.
Passat 2011 ➤ , Passat Variant 2011 ➤
General body repairs, exterior - Edition 06.2019
156 Rep. gr.58 - Rear doors, door components
