4.4 Removing and installing tank flap unit
4.4.1 Removing
Note
The description also applies to the tank flap unit with gas filler neck.
– Remove tank cap.
– Unscrew bolt -2-.
– Fold up boot of fuel filler neck.
– Pull out tank flap unit -1- with drain hose -3- backwards from
retainers and swing out tank flap unit -1- from side panel.
– Unclip assembly part -4- out of side panel and pull assembly
part off release rod -5-.
Passat 2011 ➤ , Passat Variant 2011 ➤
General body repairs, exterior - Edition 06.2019
86 Rep. gr.55 - Bonnet, rear lid
