10 - Release button
❑ Removing ⇒ page 67
3.3 Removing and installing rear lid
3.3.1 Removing
– Remove rear lid trim ⇒ General body repairs, interior; Rep.
gr. 70 ; Rear lid trim; Removing and installing rear lid trim
(estate)
– Carefully lever cover -2- out of locking device on hinge.
– Disconnect all connections in rear lid.
– Release boot -4- and guide electrical wiring through opening
in rear lid.
Further removal requires the help of a second mechanic.
– Loosen bolts -6-, do not remove.
– Remove gas strut -5- ⇒ page 75 .
Passat 2011 ➤ , Passat Variant 2011 ➤
General body repairs, exterior - Edition 06.2019
60 Rep. gr.55 - Bonnet, rear lid
