2.4 Removing and installing door
Note
♦
The removal and installation procedure is only described for
the right door. The removal and installation procedure for the
left door is basically the same.
♦
3 different type of lower hinge are used.
♦
Either the hinge parts of the lower hinge are connected with a
bolt -4-.
♦
Or the hinge parts of the lower hinge are connected with a nut
-3-.
♦
Or the hinge is simply pushed on and is attached to the door
by the screw -2-.
♦
If a new hinge is installed, it must be greased. Work specifi‐
cations can be found in the “Maintenance manual” ⇒ Mainte‐
nance ; Booklet 21.1 .
2.4.1 Removing
Passat 2011 ➤ , Passat Variant 2011 ➤
General body repairs, exterior - Edition 06.2019
142 Rep. gr.58 - Rear doors, door components
