Centring pins must align with markings -arrow- on left and right
guide plates.
If this is not the case, adjust parallel running ⇒ page 202 .
2.8 Adjusting parallel running of solar panel
Note
The parallel running adjustment can only be undertaken when the
drive and solar panel are removed (zero position).
– Removing sunroof drive ⇒ page 203 .
– Move guide plate by hand only.
Centring pins must align with markings -arrow- on left and right
guide plates.
– Refit the drive and solar panel.
2.9 Renewing panel seal
– Removing the sliding/tilting sunroof solar panel ⇒ page 203 .
– Detach seal -1- from solar panel.
– Press the new seal into solar panel -2-.
Note
To ease fitting of seal, coat panel edge with a soapy solution.
2.10 Removing wind deflector
– Open sunroof completely.
Passat 2011 ➤ , Passat Variant 2011 ➤
General body repairs, exterior - Edition 06.2019
202 Rep. gr.60 - Sunroof
