15 Lettering and emblems
15.1 Removing and installing emblems at rear
Note
The badge cannot be removed without damage.
Removing
– Use a screwdriver -3- to carefully lever manufacturer emblem
-1- off swivel badge -2- in -direction of arrow A-.
Installing
– Press manufacturer emblem -1- onto swivel badge -2- until it
engages audibly.
15.2 Tools
Special tools and workshop equipment required
Passat 2011 ➤ , Passat Variant 2011 ➤
General body repairs, exterior - Edition 06.2019
15. Lettering and emblems 457
