1 - Rear windscreen
❑ Removing rear window
⇒ page 329 .
❑ Installing rear window
⇒ page 331 .
2 - Rear lid
3 - Spacers
4 - PUR adhesive sealant
❑ Cross section of bead:
Width = 6.5 mm Height
= 10 mm (including pre‐
coating, residual materi‐
al on window glass and
window flange).
❑ Minimum curing period
⇒ page 341 .
5 - Window heater contact
6 - Side panel
1.12 Removing undamaged rear window (es‐
tate)
– If fitted, remove roof spoiler ⇒ page 449 .
– Remove window frame ⇒ General body repairs, interior; Rep.
gr. 70 ; Rear lid trim; Removing and installing window frame
trim (estate)
Passat 2011 ➤ , Passat Variant 2011 ➤
General body repairs, exterior - Edition 06.2019
1. Flush bonded windows 329
