– Remove securing screws (Torx insert -T25- ; 5 Nm).
– Remove solar panel upwards.
2.5 Installing sliding/tilting sunroof solar
panel
• Panel must be installed in the zero position (panel closed).
2.5.1 Zero position:
Centring pins must align with markings -arrow- on left and right
guide plates.
If this is not the case, adjust parallel running ⇒ page 202 .
– Place sunroof panel on from above and screw in securing
screws (guide plate to panel).
– Lightly tighten securing screws (Torx -T25- ).
Note
After adjusting panel height, tighten securing screws 5 Nm.
2.6 Adjusting sliding/tilting sunroof solar
panel height
– Open sliding/tilting sunroof about 10 cm rearwards.
Passat 2011 ➤ , Passat Variant 2011 ➤
General body repairs, exterior - Edition 06.2019
200 Rep. gr.60 - Sunroof
