Xerox VersaLink B7030 Service Manual

April 2017
2-558
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
124-313, 124-356, 124-315, 317, 355
Launch Issue
Status Indicator RAPs
124-313, 124-356 DC132 Error 10 RAP
124-313 Stored data mismatch. The serial numbers do not match.
124-356 Serial number 1 point mismatch.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Switch off, then switch on the machine, GP 10. The fault persists.
YN
Perform SCP 5 Final Actions.
Enter dC132 Device ID and Billing Data. All three serial numbers are different.
YN
Install a new drive PWB, PL 1.10 Item 3 and ESS PWB, PL 3.10 Item 6.
Perform dC132. Make all three serial numbers the same.
124-315, 317, 355 DC132 Error 02, 04 and 14 RAP
124-315 Stored data mismatch. Internal control error was detected.
124-317 Stored data mismatch. Internal control error was detected.
124-355 At least one set of territory information at the 3 locations is different.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Switch off, then switch on the machine, GP 10. The fault persists.
YN
Perform SCP 5 Final Actions.
Enter dC131. Compare NVM values 700-600, 700-601 and 700-602. All three values are dif-
ferent.
YN
Install a new drive PWB, PL 1.10 Item 3 and ESS PWB, PL 3.10 Item 6.
Perform dC132. Make all three values the same.
