Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
012-161A, 012-210
Status Indicator RAPs
Launch Issue
YN
Install a new eject home sensor, PL 12.26 Item 9.
Check the wires and connectors for an intermittent open or short circuit. If the fault per-
sists, install a new finisher PWB, PL 12.14 Item 1.
Enter dC330 code 012-054 and 012-056 alternately. The eject motor runs.
YN
Check the connections of P/J8706 and P/J8741. The connectors are good.
YN
Secure the connections.
Check for an open or short circuit between P/J8706 and P/J8741. The wiring is good.
YN
Repair the open or short circuit.
Measure the voltage between the finisher PWB P/J8706 pin 13 (+) and ground (-), and
between P/J8706 pin 15 (+) and ground (-).
The voltage is approximately +24VDC.
YN
Check the +24VDC circuit. Refer to the Wiring Diagrams.
Check the eject motor drive mechanism for deformed parts, broken parts, and/or belt
damage
The drive mechanism is good.
YN
Repair defects or damage to the drive mechanism. Install new components as nec-
essary, PL 12.25.
Install a new eject motor, PL 12.25 Item 15. If the fault persists, install a new finisher
PWB, PL 12.14 Item 1.
Check the wires and connectors for an intermittent open or short circuit. If the fault persists,
install a new finisher PWB, PL 12.14 Item 1.
012-210 NVM Fail Entry RAP
012-210 An error is detected at NVM access.
Procedure
Go to the relevant procedure:
• Integrated office finisher installed, 012-210A NVM Fail RAP.
• Office finisher LX installed, 012-210B Stacker Tray Fail RAP.
A
To Next Page
