Xerox VersaLink B7030 Service Manual

April 2017
2-566
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
124-347, 124-349
Launch Issue
Status Indicator RAPs
124-347 Billing CountType Restoration Fail RAP
124-347 Billing count type fail (one mismatches the others but cannot be automatically
repaired.)
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Switch off, then switch on the machine, GP 10. The fault persists.
YN
Perform SCP 5 Final Actions.
Enter dC131. Compare NVM values 720-052 and 720-063. Both values are different.
YN
Install a new drive PWB, PL 1.10 Item 3.
Install a new ESS PWB, PL 3.10 Item 6.
124-349 Modal Break Point Restoration Fail RAP
124-349 Modal break point fail (one mismatches the others but cannot be automatically
repaired.)
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Switch off, then switch on the machine, GP 10. The fault persists.
YN
Perform SCP 5 Final Actions.
Enter dC131. Compare NVM values 720-057 and 720-064. Both values are different.
YN
Install a new drive PWB, PL 1.10 Item 3.
Install a new ESS PWB, PL 3.10 Item 6.
