7.1 Utility—Diagnosis
7.1.1 Utility—Diagnosis—Card Diagnosis
Performs diagnostic tests on cards installed in the PBX, to identify the source of problems.
If any of the tests listed here returns the result "NG" ("No Good"), contact your dealer.
When testing is complete, any cards that were set to OUS status must be returned to INS status if they are to
be used again.
This screen can be accessed only in On-line mode.
Card Test
Tests the relevant functions of a card to ensure that it is operating correctly. The tests carried out vary according
to the type of card being tested.
The tests that are performed on each card are listed below.
Test Type
Available Cards
Local loop back diagnosis DLC2, DLC8, DLC16, LCOT6 (Pre-installed/Option), PRI30/E1
DTMF Receive test port DHLC4, MCSCL8, MCSLC16 (Pre-installed/Option)
PT loop back diagnosis DLC2, DLC8, DLC16, DHLC4
To perform a card test
1. Click on the Status cell of the card to be tested, and set it to "OUS".
2. Click on the cell showing the card type.
A new window will be displayed.
3. Select the Card Test option, and then click Execute.
The error report will be displayed. When all tests are completed, the words "Test End!" will be shown on
the last line of the output.
4. Select an option:
• Click Capture if you want to save the displayed information.
1. Specify a save destination and file name.
2. Click Save.
• Click Cancel to return to the Diagnosis screen.
100 PC Programming Manual
7.1.1 Utility—Diagnosis—Card Diagnosis
To Next Page
