Panasonic KX-NS500 Pc Programming Manual

14.4 PBX Configuration—[6-4] Feature—Second Dial
Tone
A programmed Pause time can be inserted automatically between the Second Dial Tone Waiting code and
the following digits. When a programmed Second Dial Tone Waiting code is dialled after seizing a trunk, a
pre-programmed number of pauses are inserted after the code.
A maximum of 100 Second Dial Tone Waiting codes can be programmed. 20 codes are displayed at a time.
To display other sets of codes, click the applicable tab.
Second Dial Tone Waiting Code
Specifies the Second Dial Tone Waiting code.
Value Range
Max. 4 digits (consisting of 0–9, *, and #)
Maintenance Console Location
14.4 PBX Configuration—[6-4] Feature—Second Dial Tone
Feature Guide References
2.5.4.7 Pause Insertion
Pause Repeating Counter
Specifies the number of pauses to be inserted when waiting for the second dial tone.
Value Range
0–20
Maintenance Console Location
14.4 PBX Configuration—[6-4] Feature—Second Dial Tone
Feature Guide References
2.5.4.7 Pause Insertion
774 PC Programming Manual
14.4 PBX Configuration—[6-4] Feature—Second Dial Tone

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
