17.1 PBX Configuration—[9-1] Private Network—TIE
Table
A TIE line is a privately leased communication line between two or more PBXs, which provides cost effective
communications between company members at different locations.
A maximum of 32 TIE Line Routing and Modification Tables can be programmed. It is necessary to make
unified tables with all PBXs at different locations in a TIE line network in order to identify the trunk route to be
used when an extension makes or receives a TIE line call.
There are two types of routing methods: the Extension Number Method, where all extensions in the network
are given a unique extension number; and the PBX Code Method, where each PBX is given a unique code,
which is dialled before the extension number to call an extension at another PBX.
Two priority sets (from a total of 8) are displayed at a time. To display other priority sets, click the applicable
tab.
Using a private network, up to 8 PBXs can share one voice mail system (centralised VM) connected to another
PBX. This can provide voice mail for extensions attached to any of the PBXs in the network.
Own PBX Code
Specifies the PBX code of the local PBX, when using PBX Code Method numbering on a TIE line network. If
this cell is left empty, the Extension Number Method is used.
Value Range
Max. 7 digits (consisting of 0–9)
Maintenance Console Location
17.1 PBX Configuration—[9-1] Private Network—TIE Table
Feature Guide References
4.2.1 TIE Line Service
Priority 1–Priority 8
Leading Number
Specifies the leading number for other PBX extension numbers or the PBX code of others in the TIE line
network.
Value Range
Max. 3 digits (consisting of 0–9, *, and #)
Maintenance Console Location
17.1 PBX Configuration—[9-1] Private Network—TIE Table
Feature Guide References
4.2.1 TIE Line Service
800 PC Programming Manual
17.1 PBX Configuration—[9-1] Private Network—TIE Table
