DSP IP Setting—DSP Card-1/DSP Card-2—MAC Address
Indicates the MAC address of the DSP card (reference only).
Value Range
00:00:00:00:00:00–FF:FF:FF:FF:FF:FF
Maintenance Console Location
27.1 Network Service—[1] IP Address/Ports—Basic Settings
Advanced Settings
LAN Port—Speed & Duplex
Specifies the connection mode of the main port. The connection is made in 100Mbps/half duplex when Auto
negotiation fails.
Value Range
Auto: Automatic mode selection
100M-Full: 100 Mbps/full duplex
100M-Half: 100 Mbps/half duplex
10M-Full: 10 Mbps/full duplex
10M-Half: 10 Mbps/half duplex
Maintenance Console Location
27.1 Network Service—[1] IP Address/Ports—Advanced Settings
LAN Port—MDI/MDIX
Specifies the cable type connected to the LAN port.
Value Range
Auto, MDI, MDIX
Maintenance Console Location
27.1 Network Service—[1] IP Address/Ports—Advanced Settings
Port Mirroring—Packet kind for mirroring
Specifies the types of packets used for port mirroring. This setting is available at Installer level only.
Value Range
Disable
LAN (All packets)
LAN (Data packets PBX)
LAN (Voice packets)
Maintenance Console Location
27.1 Network Service—[1] IP Address/Ports—Advanced Settings
PC Programming Manual 981
27.1 Network Service—[1] IP Address/Ports

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
