Panasonic KX-NS500 Pc Programming Manual

Two-way Recorded Message Save Mode
Specifies whether two-way recording sessions are saved in the mailboxes of subscribers in the Class of Service
as "old" or "new" messages.
Value Range
Save as Old, Save as New
Maintenance Console Location
21.1 UM Configuration—[2] Class of Service—Mailbox
Feature Guide References
3.2.2.30 Two-way Record/Two-way Transfer
Call Transfer
Intercom Paging Group
Specifies the Intercom Paging group number available to subscribers in the Class of Service.
Note
This setting is not available for COS 65 (Message Manager).
Value Range
1–32, ALL
Maintenance Console Location
21.1 UM Configuration—[2] Class of Service—Call Transfer
PC Programming Manual References
24.4 UM Configuration—[5-4] System Parameters—Parameters—Intercom Paging Parameters
Use Call Waiting on Busy
If set to "Yes", the system signals subscribers in the Class of Service when they are on a call and another call
is received.
Note
This setting is not available for COS 65 (Message Manager).
Value Range
No, Yes
Maintenance Console Location
21.1 UM Configuration—[2] Class of Service—Call Transfer
898 PC Programming Manual
21.1 UM Configuration—[2] Class of Service

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
