13.1 PBX Configuration—[5-1] Optional
Device—Doorphone
The settings to establish doorphone calls can be programmed.
To assign destinations for doorphone calls easily, click Destination Setting (see 2.1.6 Extension Number
Setting).
The Shelf, Slot, and Port for each item are displayed for your reference. For details, see Common
Programming Reference Items in 9.1 PBX Configuration—[1-1] Configuration—Slot.
DOORPHONE Number
Indicates the number of the doorphone (reference only).
Value Range
Doorphone number
Maintenance Console Location
13.1 PBX Configuration—[5-1] Optional Device—Doorphone
Feature Guide References
2.18.1 Doorphone Call
Name
Specifies the doorphone name.
Value Range
Max. 20 characters
Maintenance Console Location
13.1 PBX Configuration—[5-1] Optional Device—Doorphone
Feature Guide References
2.18.1 Doorphone Call
Destination—Day, Lunch, Break, Night
Specifies the destination number of doorphone calls for each port in each time mode.
Value Range
Max. 32 digits (consisting of 0–9, *, #, [ ] [Secret], and P [Pause])
Maintenance Console Location
13.1 PBX Configuration—[5-1] Optional Device—Doorphone
738 PC Programming Manual
13.1 PBX Configuration—[5-1] Optional Device—Doorphone

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
