9.8 PBX Configuration—[1-1]
Configuration—Slot—V-SIPGW—Shelf Property
Common settings for all of the V-SIPGW cards installed in the Virtual Shelf can be programmed.
Icon Description
In this section, the following icons show the different parameter type.
Icon
Description for Parameter Type
Manual programming is compulsory under certain conditions.
Manual programming is optional.
Main
SIP Client Port Number
Specifies the port number of the PBX used for communications with the SIP server.
Value Range
1024–65535
Maintenance Console Location
9.8 PBX Configuration—[1-1] Configuration—Slot—V-SIPGW—Shelf Property
NAT Traversal
Specifies the NAT traversal method.
– STUN: A STUN Server, used alongside the SIP Server, finds out the global IP address of the router with
NAT enabled.
– Fixed IP Addr.: The global IP address of the router with NAT enabled is fixed.
Note
Manual programming is optional except when programming is required depending on the network
conditions.
Value Range
Off, Fixed IP Addr., STUN
Maintenance Console Location
9.8 PBX Configuration—[1-1] Configuration—Slot—V-SIPGW—Shelf Property
NAT - Voice (RTP) UDP Port No.
Specifies the starting port number of the dynamic ports used for NAT Traversal.
Value Range
1024–65535
244 PC Programming Manual
9.8 PBX Configuration—[1-1] Configuration—Slot—V-SIPGW—Shelf Property
