12.1 PBX Configuration—[4-1] Extension—Wired
Extension
12.1.1 PBX Configuration—[4-1-1] Extension—Wired
Extension—Extension Settings
For each slot in which an extension card is installed, a certain number of extension ports are displayed. For
each extension port, various extension settings can be assigned.
To search for a specific extension, enter the extension number or the extension name in the search box and
click Find Next.
To copy the settings of an extension to another extension, click Copy to. The copied data includes FWD/DND,
personal speed dialling, and flexible button settings.
To assign a set of CLIP numbers automatically, click CLIP Generate.
The Shelf, Slot, and Port for each item are displayed for your reference. For details, see Common
Programming Reference Items in 9.1 PBX Configuration—[1-1] Configuration—Slot.
Main
Extension Number
Specifies the extension number of the extension.
Value Range
Max. 5 digits (consisting of 0–9)
Maintenance Console Location
12.1.1 PBX Configuration—[4-1-1] Extension—Wired Extension—Extension Settings
Extension Name
Specifies the name of the extension.
Value Range
Max. 20 characters
Maintenance Console Location
12.1.1 PBX Configuration—[4-1-1] Extension—Wired Extension—Extension Settings
Port Type
Indicates the extension port type (reference only).
Value Range
DPT: DPT port (DLC)
SLT: SLT port (MCSLC)
S-Hybrid: Super Hybrid port (DHLC)
S-Hybrid (SLT): XDP port of Super Hybrid port (DHLC)
S-Hybrid (S-DPT): Digital XDP port of Super Hybrid port (DHLC)
630 PC Programming Manual
12.1.1 PBX Configuration—[4-1-1] Extension—Wired Extension—Extension Settings
