9.1 PBX Configuration—[1-1] Configuration—Slot
The operating characteristics associated with each service card can be programmed.
Move the mouse pointer over an installed card to display the menu of options for that card. To view a summary
of status and versions for all cards installed in the PBX, click the Slot Summary button (see 9.2 PBX
Configuration—[1-1] Configuration—Slot—System Property).
To select a shelf in the PBX
Click one of the following buttons to view the shelf in the PBX:
• Basic Unit: View the basic unit.
• Expansion Unit1: View the physical card shelf of the Expansion Unit connected to connection port 1 of
the EXP-M card.
• Expansion Unit2: View the physical card shelf of the Expansion Unit connected to connection port 2 of
the EXP-M card.
• Expansion Unit3: View the physical card shelf of the Expansion Unit connected to connection port 3 of
the EXP-M card.
• Virtual Slot: View the virtual card shelf.
To install a new physical card to the PBX
1. Click on the name of the card to install in the list on the right.
An image of the card will be displayed, and information about the card will be shown.
2. Click and drag the image of the card to the slot, and release it.
The card will move into the slot space.
3. Click OK to confirm.
To add new virtual cards to the PBX
1. Click on the name of the card to install at the top.
2. Click and drag the image of the card to the slot, and release it. The card will move into the slot space.
3. Click OK to confirm.
To access card properties
1. Move the mouse pointer over a card.
A menu will be shown under the mouse pointer.
2. Select Card Property.
The property screen for that card will be displayed.
To access port properties
1. Move the mouse pointer over a card. For combination physical cards, move the mouse pointer over the
individual card name.
A menu will be shown under the mouse pointer.
2. Select Port Property.
The property screen for that card’s port or ports will be displayed.
170 PC Programming Manual
9.1 PBX Configuration—[1-1] Configuration—Slot
