Panasonic KX-NS500 Pc Programming Manual

10.7.1 PBX Configuration—[2-7-1] System—Class of Service—COS Settings—Executive— Executive Busy
Override Deny
Feature Guide References
2.10.2 Executive Busy Override
Not Ready (Manual Wrap-up) Mode On / Off
Specifies the feature number used to enter or leave Not Ready mode.
Value Range
Max. 4 digits (consisting of 0–9, *, and #)
Maintenance Console Location
10.6.1 PBX Configuration—[2-6-1] System—Numbering Plan—Main
PC Programming Manual References
11.5.1 PBX Configuration—[3-5-1] Group—Incoming Call Distribution Group—Group Settings
Feature Guide References
2.2.2.7 Log-in/Log-out
Log-in / Log-out
Specifies the feature number used to join or leave an incoming call distribution group.
Value Range
Max. 4 digits (consisting of 0–9, *, and #)
Maintenance Console Location
10.6.1 PBX Configuration—[2-6-1] System—Numbering Plan—Main
PC Programming Manual References
11.5.1 PBX Configuration—[3-5-1] Group—Incoming Call Distribution Group—Group Settings
Feature Guide References
2.2.2.7 Log-in/Log-out
Incoming Call Queue Monitor
Specifies the feature number, available only for extensions assigned as a supervisor, used to monitor the status
of an incoming call distribution group with the extension display.
Value Range
Max. 4 digits (consisting of 0–9, *, and #)
PC Programming Manual 479
10.6.1 PBX Configuration—[2-6-1] System—Numbering Plan—Main

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
