7.4.3 Utility—Monitor/Trace—V-SIPGW Protocol Trace
The trace data of protocol activity can be collected from the V-SIPGW16 card and saved to a PC using the
V-SIPGW Protocol Trace.
This option requires that the target V-SIPGW16 card be set to INS status.
This option is only available at Installer level in On-line mode.
Follow the steps below to trace and file V-SIPGW16 card protocol activity:
To save trace data to the System Memory
1. From the tree menu, select V-SIPGW Protocol Trace.
When the progress bar disappears, the protocol trace is complete. The trace data has been saved to the
System Memory (file name: "PRTSIPC").
To transfer trace data to the PC
1. Click the File Transfer PBX to PC link to access the file transfer screen.
The list of files will be displayed.
Note
The file transfer screen can also be accessed from the tree menu (see 7.2.2 Utility—File—File
Transfer PBX to PC).
2. Select the desired trace data file.
3. Click Transfer.
4. Navigate to the folder in which you want to save the file.
5. Enter a file name.
6. Click Save.
7. Click OK.
116 PC Programming Manual
7.4.3 Utility—Monitor/Trace—V-SIPGW Protocol Trace

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
