Panasonic KX-NS500 Pc Programming Manual

11.10 PBX Configuration—[3-10] Group—P2P Group
Settings for peer-to-peer (P2P) groups can be programmed.
P2P Group Name
Specifies the name of the P2P group.
Value Range
Max. 20 characters
Maintenance Console Location
11.10 PBX Configuration—[3-10] Group—P2P Group
Feature Guide References
5.2.3 Peer-to-Peer (P2P) Connection
Bandwidth Control
Specifies whether to use the bandwidth precedence setting of the P2P group for calling among different P2P
groups.
Value Range
Disable, Enable
Maintenance Console Location
11.10 PBX Configuration—[3-10] Group—P2P Group
Feature Guide References
5.2.3 Peer-to-Peer (P2P) Connection
612 PC Programming Manual
11.10 PBX Configuration—[3-10] Group—P2P Group

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
