9.33 PBX Configuration—[1-1]
Configuration—Slot—DOORPHONE Card—Card
Property
The doorphone card’s settings can be programmed.
The Shelf, Slot, and Port for each item are displayed for your reference. For details, see Common
Programming Reference Items in 9.1 PBX Configuration—[1-1] Configuration—Slot.
Port Status
Specifies the port’s status.
This option is only available in On-line mode.
Value Range
INS: The port is in service.
OUS: The port is out of service.
Fault: There is a communication error.
Maintenance Console Location
9.33 PBX Configuration—[1-1] Configuration—Slot—DOORPHONE Card—Card Property
For Output - Device Type
Selects the type of connected output device (for output ports only).
Value Range
Ringer, Relay, Door Opener
Maintenance Console Location
9.33 PBX Configuration—[1-1] Configuration—Slot—DOORPHONE Card—Card Property
For Sensor - Input Signal Decision Time
Specifies the minimum duration of continuous input from the triggered sensor before the PBX recognises the
input and makes a sensor call.
Value Range
32 ´ n (n=2–255) ms
Maintenance Console Location
9.33 PBX Configuration—[1-1] Configuration—Slot—DOORPHONE Card—Card Property
For Sensor - Input Signal Detection Reopening Time
Specifies the length of time after the sensor has been triggered during which any further input from the sensor
will be ignored.
PC Programming Manual 413
9.33 PBX Configuration—[1-1] Configuration—Slot—DOORPHONE Card—Card Property
