Panasonic KX-NS500 Pc Programming Manual

9.31 PBX Configuration—[1-1]
Configuration—Slot—Port Property—E1 Port
Various settings can be programmed for each E1 channel. To change the status of ports, click Command.
Shelf
Indicates the shelf position (reference only).
Value Range
Shelf number
Maintenance Console Location
9.31 PBX Configuration—[1-1] Configuration—Slot—Port Property—E1 Port
Slot
Indicates the slot position (reference only).
Value Range
Slot number
Maintenance Console Location
9.31 PBX Configuration—[1-1] Configuration—Slot—Port Property—E1 Port
CH
Indicates the channel number (reference only).
Value Range
channel number
Maintenance Console Location
9.31 PBX Configuration—[1-1] Configuration—Slot—Port Property—E1 Port
Connection
Indicates the channel status (reference only).
This column offers two ways to open the screen to select the channel command:
• Click the desired cell in the column.
• Select the desired cell in the column, and then click Command.
Value Range
INS: The channel is in service.
OUS: The channel is out of service.
Fault: The channel is not communicating with the network.
406 PC Programming Manual
9.31 PBX Configuration—[1-1] Configuration—Slot—Port Property—E1 Port

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
