Panasonic KX-NS500 Pc Programming Manual

18.3.1 PBX Configuration—[10-3] CO & Incoming Call—DDI / DID
Table—Automatic Registration
Automatic Registration allows DDI/DID numbers and DDI/DID destinations in each time mode (day/lunch/
break/night) to be programmed at once for a set of locations in series.
Beginning Entry Location
Specifies the number of the first location to be programmed.
Value Range
1–1000
Maintenance Console Location
18.3.1 PBX Configuration—[10-3] CO & Incoming Call—DDI / DID Table—Automatic Registration
PC Programming Manual References
18.3 PBX Configuration—[10-3] CO & Incoming Call—DDI / DID Table
Feature Guide References
2.1.1.3 Direct Inward Dialling (DID)/Direct Dialling In (DDI)
Generate DDI/DID Number (From)
Specifies the DID number of the first location to be programmed. DDI/DID numbers for subsequent locations
will be generated automatically, by adding one to the value of the previous location.
Value Range
Max. 32 digits (consisting of 0–9)
Maintenance Console Location
18.3.1 PBX Configuration—[10-3] CO & Incoming Call—DDI / DID Table—Automatic Registration
PC Programming Manual References
18.3 PBX Configuration—[10-3] CO & Incoming Call—DDI / DID Table
Feature Guide References
2.1.1.3 Direct Inward Dialling (DID)/Direct Dialling In (DDI)
Number of Registration
Specifies the number of locations to be programmed.
Value Range
1–1000
822 PC Programming Manual
18.3.1 PBX Configuration—[10-3] CO & Incoming Call—DDI / DID Table—Automatic Registration

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
