Panasonic KX-NS500 Pc Programming Manual

12.1.5 PBX Configuration—[4-1-5] Extension—Wired
Extension—PF Button
Each Programmable Feature (PF) button can be customised to access a certain feature with one touch. A
maximum of 12 PF buttons can be customised for each extension. Select the desired extension from the
Extension Number / Name list.
Type
Specifies whether to store a dialling number for the one-touch access.
Value Range
Not Stored, One Touch
Maintenance Console Location
12.1.5 PBX Configuration—[4-1-5] Extension—Wired Extension—PF Button
Feature Guide References
2.21.2 Flexible Buttons
Dial
Specifies the number to be dialled.
Value Range
Max. 32 digits (consisting of 0–9, *, #, T [Transfer], [ ] [Secret], P [Pause], and F [Flash])
Maintenance Console Location
12.1.5 PBX Configuration—[4-1-5] Extension—Wired Extension—PF Button
Feature Guide References
2.21.2 Flexible Buttons
PC Programming Manual 675
12.1.5 PBX Configuration—[4-1-5] Extension—Wired Extension—PF Button

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
