Panasonic KX-NS500 Pc Programming Manual

27.3 Network Service—[3] Client Feature
27.3.1 Network Service—[3-1] Client Feature—FTP
FTP client connection settings can be programmed. Up to 5 FTP sites can be specified for connections.
Connection 1—Connection 5
Connection Name
Specifies the name of the connection to use for programming in other items.
Value Range
Max. 64 characters
Maintenance Console Location
27.3.1 Network Service—[3-1] Client Feature—FTP
IP Address
Specifies the IP address of the FTP site. Click the IP Address radio button when this is used.
Value Range
1.0.0.0–223.255.255.255
Maintenance Console Location
27.3.1 Network Service—[3-1] Client Feature—FTP
Name
Specifies the name of the FTP site. Click the Name radio button when this is used.
Value Range
FTP site name (max. 253 characters)
Maintenance Console Location
27.3.1 Network Service—[3-1] Client Feature—FTP
Server Port Number
Specifies the port number used to connect to the FTP site.
Value Range
21, 990, 1024–65535
Maintenance Console Location
27.3.1 Network Service—[3-1] Client Feature—FTP
PC Programming Manual 997
27.3.1 Network Service—[3-1] Client Feature—FTP

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
