Panasonic KX-NS500 Pc Programming Manual

6.3 Tool—Call Pickup for My Group
Allows you to automatically configure settings in 10.6.2 PBX Configuration—[2-6-2] System—Numbering
Plan—Quick Dial and 12.1.3 PBX Configuration—[4-1-3] Extension—Wired Extension—Speed Dial so
that users can answer calls to their Call Pickup Group by pressing " 0".
To activate this tool
1. When this tree menu item is selected, a confirmation screen will be displayed.
2. Click Yes.
The Group Call Pickup feature number (default: 40) + the extension user group number of the extension
is assigned to first personal speed dial.
Note
This tool can only be activated if all of the following conditions are met:
– The first Quick Dial setting is empty or is already set to " 0".
– " 0" is not used for another feature number.
– The Group Call Pickup feature number has been assigned.
– The Personal Speed Dialling feature number has been assigned.
PC Programming Manual 79
6.3 Tool—Call Pickup for My Group

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
