Panasonic KX-NS500 Pc Programming Manual

8.3 Users—Automatic Two-way Recording
This screen is accessible only by users designated as Automatic Two-way Recording supervisors. See
7.10.1 Utility—Automatic Two-way Recording—Supervisor Setting.
This screen can be accessed only in On-line mode.
8.3.1 Users—Automatic Two-way Recording—Edit a Recording
On this screen, a user designated as a supervisor may change Automatic Two-way Recording settings for
extensions they are supervising. Information for each extension, including the extension’s supervisor, and
Automatic Two-way Recording destination mailbox is displayed.
You can specify which types of calls will recorded for each extension.
1. For an extension, click the setting for Internal Call, External Call, or ICDG Incoming Only.
• Internal Call: Extension-to-extension calls are recorded.
• External Call: Calls with outside parties are recorded.
• ICDG Incoming Only: Only calls that are received by the extension through an incoming call
distribution group are recorded.
2. Select On or Off for that setting.
Note
To set ICDG Incoming Only to "On", External Call must first be set to "On".
3. Click OK when finished.
156 PC Programming Manual
8.3.1 Users—Automatic Two-way Recording—Edit a Recording

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
