Panasonic KX-NS500 Pc Programming Manual

27.2.3 Network Service—[2-4] Server Feature—HTTP
HTTP server settings can be programmed.
HTTP (LAN)—Port number
Specifies the port number for HTTP connections using the LAN ports. This port is used for accessing the PBX
for Web Maintenance Console programming.
Value Range
80, 1024–65535
Maintenance Console Location
27.2.3 Network Service—[2-4] Server Feature—HTTP
HTTP (LAN)—HTTPs server
Enables or disables HTTPs for connections to the LAN ports using the PBX’s HTTP server function.
Value Range
Disable, Enable
Maintenance Console Location
27.2.3 Network Service—[2-4] Server Feature—HTTP
HTTPs (LAN) —Port number
Specifies the port number for HTTPs connections. This port is used for accessing the PBX for Web
Maintenance Console programming when using an SSL connection.
Value Range
443, 1024–65535
Maintenance Console Location
27.2.3 Network Service—[2-4] Server Feature—HTTP
Automatic logout Timer (min)
Specifies the amount of time required to elapse before logging off an inactive connection from the HTTP server.
Value Range
5, 10, 30, 60´n (n=1–24) (minutes)
Maintenance Console Location
27.2.3 Network Service—[2-4] Server Feature—HTTP
PC Programming Manual 989
27.2.3 Network Service—[2-4] Server Feature—HTTP

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
