Panasonic KX-NS500 Pc Programming Manual

13.4 PBX Configuration—[5-4] Optional
Device—External Relay
Settings related to external relays can be programmed.
Before programming these settings, For Output - Device Type must be set to "Relay" in the
DOORPHONE card’s property settings. (® 9.33 PBX Configuration—[1-1]
Configuration—Slot—DOORPHONE Card—Card Property)
The Shelf, Slot, and Port for each item are displayed for your reference. For details, see Common
Programming Reference Items in 9.1 PBX Configuration—[1-1] Configuration—Slot.
External Relay No.
Indicates the number of the external relay (reference only).
Value Range
1–8
Maintenance Console Location
13.4 PBX Configuration—[5-4] Optional Device—External Relay
Feature Guide References
2.18.4 External Relay Control
Name
Specifies the relay name.
Value Range
Max. 20 characters
Maintenance Console Location
13.4 PBX Configuration—[5-4] Optional Device—External Relay
Feature Guide References
2.18.4 External Relay Control
Relay Activate Time
Specifies the length of time that the relay stays on when activated.
Value Range
1–7 s
Maintenance Console Location
13.4 PBX Configuration—[5-4] Optional Device—External Relay
PC Programming Manual 753
13.4 PBX Configuration—[5-4] Optional Device—External Relay
