Panasonic KX-NS500 Pc Programming Manual

5.2.2 System Control—MOH—Delete
MOH files that are occupying BGM numbers can be deleted.
This screen can be accessed only in On-line mode.
1. In BGM No., specify the BGM numbers to delete MOH files from. Specify "All" to delete the data saved in
all BGM numbers.
2. Click Execute to delete the files of the specified BGM numbers.
Note
• User (User) level accounts cannot perform this procedure.
70 PC Programming Manual
5.2.2 System Control—MOH—Delete

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
