9.24 PBX Configuration—[1-1]
Configuration—Slot—Port Property - LCO Port
Various settings can be programmed for each analogue trunk port.
The Shelf, Slot, and Port for each item are displayed for your reference. For details, see Common
Programming Reference Items in 9.1 PBX Configuration—[1-1] Configuration—Slot.
Port Type
Select to use the port with either the CO, MOH, or External Pager features. (Only LCOT6 is installed by
default.)
2 ports, an odd and an even port, are programmed in a pair.
Value Range
CO, MOH, External Pager
Maintenance Console Location
9.24 PBX Configuration—[1-1] Configuration—Slot—Port Property - LCO Port
Installation Manual References
4.3.4 LCOT6 in KX-NS500 (installed by default)
Connection
Indicates the port status. To change the status of the port, click the desired cell in the column, and then select
INS or OUS for the port.
This option is only available in On-line mode.
This option can only be changed when CO is selected for the Port Type.
Value Range
INS: The port is in service.
OUS: The port is out of service.
Maintenance Console Location
9.24 PBX Configuration—[1-1] Configuration—Slot—Port Property - LCO Port
Busy Out Status
Indicates the Busy Out status (reference only).
Value Range
Normal, Busy Out
Maintenance Console Location
9.24 PBX Configuration—[1-1] Configuration—Slot—Port Property - LCO Port
366 PC Programming Manual
9.24 PBX Configuration—[1-1] Configuration—Slot—Port Property - LCO Port
