Panasonic KX-NS500 Pc Programming Manual

6.4 Tool—Extension List View
Displays a list of all programmed extension numbers and types. It is possible to sort the information according
to Extension Number, Type, Extension Name, Shelf, Slot, or Port. There is also a key-word searching feature.
The types that can be displayed are as follows:
Type Detail
Intercom Wired Extension
Portable Station Wireless Extension (Portable Station)
SIP / IP-PT / S-PS SIP/IP-PT/S-PS Extension
UM / VM Unified Messaging UM Group/VPS Voice Mail
ICD Group Incoming Call Distribution Group
PS Ring Group Portable Station Ring Group
UM Group Unified Messaging UM Group
VM(DPT) Group VM (DPT) Group
VM(DTMF) Group VM (DTMF) Group
Pager External Pager
OGM (DISA) DISA
DSS DSS Console
DPT-I/F CS PT-interface CS
SVM Simplified Voice Message
MODEM MODEM
ISDN Remote ISDN Remote
80 PC Programming Manual
6.4 Tool—Extension List View

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
