17.3 PBX Configuration—[9-3] Private
Network—Network Operator (VoIP)
This screen allows network operators to be programmed. A network operator is an extension at a remote PBX
that will monitor other PBX extensions using Network Direct Station Selection (NDSS). The settings on this
screen should be programmed at the PBX that is to be monitored ( Network Data Transmission for
Centralised Operator Feature—Network PBX ID 2–8). Up to 8 network operators can be programmed.
Network Operator Extension No.
Specifies the number of an extension at the monitor PBX (the PBX whose
Network Data Transmission
for Centralised Operator Feature—Network PBX ID is set to 1 in 17.2 PBX Configuration—[9-2] Private
Network—Network Data Transmission). Any extension at the monitor PBX can be specified here.
Value Range
Max. 16 digits (consisting of 0–9, *, and #)
Maintenance Console Location
17.3 PBX Configuration—[9-3] Private Network—Network Operator (VoIP)
PC Programming Manual References
17.2 PBX Configuration—[9-2] Private Network—Network Data Transmission— Network Data Transmission
for Centralised Operator Feature—Network PBX ID
Feature Guide References
4.2.5.1 Network Direct Station Selection (NDSS)
IP-GW Card Slot No. to notify BLF data to Network Operator
Specifies the slot number of the card used to send extension status data. This setting is only required when
using VoIP to transmit data.
Value Range
Undefined, 1 – 4, 1 – 5, 2 – 2, 2 – 3, 3 – 2, 3 – 3, 4 – 2, 4 – 3, Virtual – 1, Virtual – 2, Virtual – 3, Virtual – 4
Maintenance Console Location
17.3 PBX Configuration—[9-3] Private Network—Network Operator (VoIP)
PC Programming Manual References
9.1 PBX Configuration—[1-1] Configuration—Slot
Feature Guide References
4.2.5.1 Network Direct Station Selection (NDSS)
806 PC Programming Manual
17.3 PBX Configuration—[9-3] Private Network—Network Operator (VoIP)
