9.27 PBX Configuration—[1-1]
Configuration—Slot—Card Property—E1 type
The properties of the E1 card can be specified.
To adjust related settings, click Line Signal Setting, MFC-R2 Setting 1, and MFC-R2 Setting 2.
Line Coding
Selects the line coding type of E1 PCM (Pulse Code Modulation) for the E1 card.
Value Range
HDB3, AMI
Maintenance Console Location
9.27 PBX Configuration—[1-1] Configuration—Slot—Card Property—E1 type
Frame Sequence
Selects the type of frame sequence for the E1 card.
Value Range
PCM30, PCM30-CRC
Maintenance Console Location
9.27 PBX Configuration—[1-1] Configuration—Slot—Card Property—E1 type
Frame Option
Selects the value for C-bit and D-bit.
Value Range
C=A, D=B; C=0, D=0; C=0, D=1; C=1, D=0; C=1, D=1
Maintenance Console Location
9.27 PBX Configuration—[1-1] Configuration—Slot—Card Property—E1 type
First Dial Timer (TIE)
Specifies the minimum time that the PBX waits after seizing a DDI/DID or TIE line, before sending the dialled
digits to the telephone company or to another PBX. This allows the telephone company or the other PBX to
have enough time to accept the dialled digits correctly..
Value Range
32 x n (n=1–255) ms
Maintenance Console Location
9.27 PBX Configuration—[1-1] Configuration—Slot—Card Property—E1 type
390 PC Programming Manual
9.27 PBX Configuration—[1-1] Configuration—Slot—Card Property—E1 type
