Panasonic KX-NS500 Pc Programming Manual

25.1 UM Configuration—[6] H/W Settings
Global Parameters
Global parameters define the settings that affect integration with other PBX operations.
Maximum Time to Wait for Dial Tone (500-20000 ms, *100 ms)
Specifies the length of time that the system waits for dial tone detection.
Value Range
5–200 (´ 100 ms)
Maintenance Console Location
25.1 UM Configuration—[6] H/W Settings—Global Parameters
Delay After Dialing Before Onhook (0-250 s)
Specifies the length of time that the system waits for an answer when making an outside call. If no answer is
detected, the system disconnects the call.
Value Range
0–250 s
Maintenance Console Location
25.1 UM Configuration—[6] H/W Settings—Global Parameters
DTMF Cut Length (0-500 ms)
Specifies the length of time for DTMF to be deleted when it is detected while recording.
Value Range
0–500 ms
Maintenance Console Location
25.1 UM Configuration—[6] H/W Settings—Global Parameters
Minimum Message Length (0-9 s)
Specifies the minimum message recording length. Messages shorter than the specified minimum recording
length are discarded from the mailbox.
Value Range
0–9 s
Maintenance Console Location
25.1 UM Configuration—[6] H/W Settings—Global Parameters
970 PC Programming Manual
25.1 UM Configuration—[6] H/W Settings

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
