Panasonic KX-NS500 Pc Programming Manual

9.30 PBX Configuration—[1-1]
Configuration—Slot—Card Property—E1 type
MFC-R2 Setting 2
Group-A Code Assignment—Address Complete
Specifies the address complete (completion of dial reception) code sent to the telephone company.
Value Range
1–15
Maintenance Console Location
9.30 PBX Configuration—[1-1] Configuration—Slot—Card Property—E1 type MFC-R2 Setting 2
Group-A Code Assignment—ANI Request
Specifies the code used to request the telephone company to send an ANI number.
Value Range
1–15
Maintenance Console Location
9.30 PBX Configuration—[1-1] Configuration—Slot—Card Property—E1 type MFC-R2 Setting 2
Group-A Code Assignment—ANI (N+1)
Specifies the code used to request the telephone company to send the (N+1)th digit of an ANI number.
Value Range
1–15
Maintenance Console Location
9.30 PBX Configuration—[1-1] Configuration—Slot—Card Property—E1 type MFC-R2 Setting 2
Group-A Code Assignment—ANI (N+1) Additional Code
Specifies the second code when two codes are needed to request the telephone company to send the (N+1)th
digit of an ANI number.
Value Range
Undefined, 1–15
Maintenance Console Location
9.30 PBX Configuration—[1-1] Configuration—Slot—Card Property—E1 type MFC-R2 Setting 2
PC Programming Manual 401
9.30 PBX Configuration—[1-1] Configuration—Slot—Card Property—E1 type MFC-R2 Setting 2

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
