Panasonic KX-NS500 Pc Programming Manual

10.8 PBX Configuration—[2-8] System—Ring Tone
Patterns
10.8.1 PBX Configuration—[2-8-1] System—Ring Tone
Patterns—Call from CO
Different ring tone patterns can be selected for incoming trunk calls depending on the trunk group that the calls
are received on. A maximum of 8 Ring Tone Pattern Tables can be programmed, and any pattern table can
be selected for use by an extension.
Ring Tone Pattern Plan 1–8
Specifies the ring tone pattern for incoming trunk calls.
Value Range
Single, Double, Triple, Option1, Option2
Maintenance Console Location
10.8.1 PBX Configuration—[2-8-1] System—Ring Tone Patterns—Call from CO
PC Programming Manual References
18.1 PBX Configuration—[10-1] CO & Incoming Call—CO Line Settings— Trunk Group Number
12.1.1 PBX Configuration—[4-1-1] Extension—Wired Extension—Extension Settings—Option 1— Ring
Pattern Table
12.2.1 PBX Configuration—[4-2-1] Extension—Portable Station—Extension Settings—Option 1— Ring
Pattern Table
Feature Guide References
2.1.3.2 Ring Tone Pattern Selection
512 PC Programming Manual
10.8.1 PBX Configuration—[2-8-1] System—Ring Tone Patterns—Call from CO

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
