Panasonic KX-NS500 Pc Programming Manual

13.5 PBX Configuration—[5-5] Optional
Device—External Sensor
Settings related to external sensors can be programmed.
To assign destinations for sensor calls easily, click Destination Setting (see 2.1.6 Extension Number
Setting).
The Shelf, Slot, and Port for each item are displayed for your reference. For details, see Common
Programming Reference Items in 9.1 PBX Configuration—[1-1] Configuration—Slot.
External Sensor No.
Indicates the number of the external sensor (reference only).
Value Range
1–8
Maintenance Console Location
13.5 PBX Configuration—[5-5] Optional Device—External Sensor
Feature Guide References
2.18.3 External Sensor
Name
Specifies the sensor name.
Value Range
Max. 20 characters
Maintenance Console Location
13.5 PBX Configuration—[5-5] Optional Device—External Sensor
Feature Guide References
2.18.3 External Sensor
Destination—Day, Lunch, Break, Night
Specifies the destination number of sensor calls for each port in each time mode.
Value Range
Max. 32 digits (consisting of 0–9, *, #, [ ] [Secret], and P [Pause])
Maintenance Console Location
13.5 PBX Configuration—[5-5] Optional Device—External Sensor
PC Programming Manual 755
13.5 PBX Configuration—[5-5] Optional Device—External Sensor

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
