Panasonic KX-NS500 Pc Programming Manual

13.2 PBX Configuration—[5-2] Optional
Device—External Pager
Settings for the external pager (external speaker) can be specified.
Click Extension List View to view a list of all programmed extension numbers and types (see
6.4 Tool—Extension List View).
ID
Indicates the External Pager ID (reference only).
Value Range
1–6
Maintenance Console Location
13.2 PBX Configuration—[5-2] Optional Device—External Pager
Floating Extension Number
Specifies the floating extension number of the external pager.
Value Range
Max. 5 digits (consisting of 0–9)
Maintenance Console Location
13.2 PBX Configuration—[5-2] Optional Device—External Pager
Feature Guide References
2.17.1 Paging
2.17.2 Trunk Answer From Any Station (TAFAS)
2.30.1 Background Music (BGM)
Name
Specifies the name of the external pager.
Value Range
Max. 20 characters
Maintenance Console Location
13.2 PBX Configuration—[5-2] Optional Device—External Pager
Feature Guide References
2.17.1 Paging
2.17.2 Trunk Answer From Any Station (TAFAS)
2.30.1 Background Music (BGM)
PC Programming Manual 741
13.2 PBX Configuration—[5-2] Optional Device—External Pager

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
