19.3 PBX Configuration—[11-3] Maintenance—Air
Synchronisation
You can programme and view settings for Air Synchronisation Groups.
Select an Air Synchronisation Group (1-4) to programme from the Air Synchronisation Group Number
drop-down list.
It is possible to synchronise CSs with each other within the air synchronisation group.
Click Sort to reorder CSs with traditional CSs first, followed by IP-CSs.
To open the screen described in 7.4.4 Utility—Monitor/Trace—CS Status Monitor, click CS Status
Monitor.
Air Synchronisation Groups can be programmed only in On-line mode.
The Shelf, Slot, and Port for each item are displayed for your reference. For details, see Common
Programming Reference Items in 9.1 PBX Configuration—[1-1] Configuration—Slot.
Adding CSs
Follow the steps below to add CSs to the air synchronisation group.
1. Connect the CS to be registered to the network and, if necessary, the power supply.
2. Click Add.
A dialogue box will appear. Non-registered (available) CSs are displayed on the left.
3. Highlight CSs and click the right arrow to select them for addition.
4. Click OK.
Deleting CSs
Follow the steps below to delete CSs from the air synchronisation group.
1. Click Delete.
A dialogue box will appear. Registered CSs are displayed on the left.
2. Highlight CSs and click the right arrow to select them for deletion.
3. Click OK.
Index
Indicates the CS number (reference only).
Value Range
1–16
Maintenance Console Location
19.3 PBX Configuration—[11-3] Maintenance—Air Synchronisation
Shelf
Indicates the shelf number (reference only).
Value Range
1: Main unit
2: Expansion Unit1
3: Expansion Unit2
4: Expansion Unit3
Virtual: Virtual Slot
PC Programming Manual 845
19.3 PBX Configuration—[11-3] Maintenance—Air Synchronisation
