9.16 PBX Configuration—[1-1]
Configuration—Slot—V-SIPEXT—Port Property
Various settings can be programmed for each virtual SIP extension port.
The Shelf, Slot, and Port for each item are displayed for your reference. For details, see Common
Programming Reference Items in 9.1 PBX Configuration—[1-1] Configuration—Slot.
Main
Extension Number
Specifies the extension number of the port.
Value Range
Max. 5 digits (consisting of 0–9)
Maintenance Console Location
9.16 PBX Configuration—[1-1] Configuration—Slot—V-SIPEXT—Port Property
Feature Guide References
5.2.2 SIP (Session Initiation Protocol) Extension
Password
Specifies the password used for registering a SIP Extension to the PBX. While it is possible to enter a password
manually for each SIP Extension, you can copy Extension Number to Password by clicking the Copy
to button. This parameter can only be modified when the virtual SIP extension port is set to OUS, and the
programmer must be in On-line mode.
Value Range
4–16 characters (consisting of 0–9, a–z, A–Z)
Maintenance Console Location
9.16 PBX Configuration—[1-1] Configuration—Slot—V-SIPEXT—Port Property
Feature Guide References
5.2.2 SIP (Session Initiation Protocol) Extension
Connection
Indicates the port status. To change the status of the port, click the desired cell in the column, and then select
INS or OUS for the port.
This option is only available in On-line mode.
Value Range
INS: The port is in service.
OUS: The port is out of service.
316 PC Programming Manual
9.16 PBX Configuration—[1-1] Configuration—Slot—V-SIPEXT—Port Property
