11.12.2 PBX Configuration—[3-12-2] Group—VM (DTMF)
Group—Group Settings
A VM (DTMF) group has a floating extension number, and can be assigned as the destination for redirected
calls and incoming calls. To assign members to the group, click Member List. To view a list of all programmed
extension numbers and types, click Extension List View.
Floating Ext. No.
Specifies the floating extension number of the VM (DTMF) group.
Value Range
Max. 5 digits (consisting of 0–9)
Maintenance Console Location
11.12.2 PBX Configuration—[3-12-2] Group—VM (DTMF) Group—Group Settings
Feature Guide References
2.28.1 Voice Mail (VM) Group
Group Name
Specifies the name of the VM (DTMF) group, which will be shown on the display of extensions that call the VM
(DTMF) group.
Value Range
Max. 20 characters
Maintenance Console Location
11.12.2 PBX Configuration—[3-12-2] Group—VM (DTMF) Group—Group Settings
Feature Guide References
2.28.1 Voice Mail (VM) Group
Type
Specifies the initial service mode in which the VPS answers calls.
Value Range
AA, VM
Maintenance Console Location
11.12.2 PBX Configuration—[3-12-2] Group—VM (DTMF) Group—Group Settings
