7.2.2 Utility—File—File Transfer PBX to PC
Copies system data files from the System Memory and SD card installed in the PBX to the connected PC.
This option is only available at Installer level when programming in On-line mode.
The files that can be downloaded from the System Memory and SD card are as follows:
File Name File Type
DFSYS System data
$SYSERR Error data
$SYSERR1–$SYSERR9
UT_ACS KX-UT series SIP phone configuration
data
• Downloading the DFSYS system data file allows you to make a backup of the configuration of the PBX.
• The error data files are snapshots of the configuration of the PBX taken automatically when a major error
causes a system reset. They can be analysed by your dealer to identify the source of a problem. If there
is only one error data file, its name will be $SYSERR. If there is more than one file, the files will be numbered
in chronological order, up to a maximum of 9 files.
• KX-UT series SIP phone configuration data can be transferred to a PC, and then imported using the
phone’s Web user interface. For details, refer to the Administrator Guide of the relevant KX-UT series SIP
phone.
To transfer files to the PC
1. Select the file to download from the list of files on System Memory and SD card.
Only the files listed in the table above can be downloaded. Selecting any other file will cause an error
message to be displayed.
2. Click Transfer.
The Save dialogue box will be displayed.
3. Navigate to the folder in which you want to save the file.
4. Enter a file name.
5. Click Save.
• A window showing the download progress will be displayed.
• A message will be displayed when the transfer is complete.
6. Click OK.
PC Programming Manual 103
7.2.2 Utility—File—File Transfer PBX to PC
