7.2 Utility—File
7.2.1 Utility—File—File Transfer PC to PBX
Copies PBX system data files from the connected PC to the System Memory installed in the PBX. Pre-existing
files in System Memory Card are overwritten.
This option is only available at Installer level when programming in On-line mode.
To install new main system data that has been copied to the PBX, use the System Reset utility (see 5.3 System
Control—System Reset) for DFSYS files.
The PBX examines the header information of a file to determine 2 things: whether the file contains supported
data, and which system component the file applies to.
Only files whose header information matches that of a system file supported by the PBX can be transferred.
Attempting to transfer any other type of file results in an error message.
The names of all files that can be stored in the System Memory are as follows:
System Data
Name on System Memory
Corresponding Card
DFSYS Mother Board
DFSYS_R Mother Board
*1
*1
DFSYS-file-format data that is transferred to the PBX is saved as "DFSYS_R".
To transfer files to the System Memory
1. The dialogue box will be displayed.
2. Select the file to upload, and click OK.
A window showing the upload progress will be displayed.
While transferring files to the System Memory, the PBX automatically renames them according to the
header information.
A message will be displayed when the transfer is complete.
3. Click OK.
102 PC Programming Manual
7.2.1 Utility—File—File Transfer PC to PBX
