Panasonic KX-NS500 Pc Programming Manual

15.3 PBX Configuration—[7-3] TRS—Special Carrier
If the PBX has access to multiple telephone companies, a Special Carrier Access Code is required each time
a trunk call is made. By programming these Special Carrier Access Codes here, Toll Restriction (TRS)/Call
Barring (Barring) can restrict or allow calls to be made by ignoring the codes and looking at the telephone
number only. If a Special Carrier Access Code is found in the dialled number, TRS/Barring will look only at the
following digits.
A maximum of 100 Special Carrier Access Codes can be programmed.
Special Carrier Access Code
Specifies a Special Carrier Access Code. Special Carrier Access Codes and Host PBX Access codes should
be unique.
Value Range
Max. 16 digits (consisting of 0–9, *, and #)
Maintenance Console Location
15.3 PBX Configuration—[7-3] TRS—Special Carrier
Feature Guide References
2.5.4.9 Special Carrier Access Code
2.7.1 Toll Restriction (TRS)/Call Barring (Barring)
782 PC Programming Manual
15.3 PBX Configuration—[7-3] TRS—Special Carrier

Panasonic KX-NS500 Specifications

General

Analog Extensions	Up to 64
VoIP Support	Yes
System Type	Hybrid IP-PBX
Power Supply	AC 100-240V, 50/60Hz
Operating Temperature	0°C to 40°C
Humidity	10% to 90% (non-condensing)
Maximum Extensions	288
IP Extensions	128
VoIP Channels	64
SIP Trunks	64
Networking	Yes, supports networking
Built-in Applications	Call Center
Expandability	Yes, via expansion cards and cabinets
Supported Protocols	SIP, H.323, MGCP
Dimensions	430 x 88 x 367 mm
